Call For Price
Specifications
| Pedal-Assist | Five levels of pedal-assist and an ergonomic thumb throttle deliver the speed and power to own the road as a Class 1, 2, or 3 eBike.** |
| Motor Controller | A 24 amp controller swiftly distributes power to the motor. |
| Semi-Integrated Battery | A removable 48V 14Ah lithium-ion battery certified to UL 2271, integrated on the down tube of the frame, makes for a clean and easily-accessible design.† The Lectric XPeak is also certified to UL 2849. |
| Suspension Front Fork | Adjustable RST Renegade suspension fork with up to 80mm of travel provides shock absorption for a smooth ride. |
| Lectric PWR™ | Lectric's new Pedal Assist Wattage Regulation (PWR) programming allows for an improved Pedal Assist experience by assisting the rider up to a certain power level for each PAS setting, instead of limiting the assistance by speed alone |
| Drivetrain | 11-28 tooth, 7-geared freewheel paired with a Shimano derailleur and a thumb-triggered handlebar shifter allows you to swiftly change gears while riding to create pedaling efficiency and an easier riding experience at higher speeds. |
| Chain | The XPeak's KMC Z7 steel chain offers consistent tension and secure performance throughout your ride. |
| Safety Lights | An integrated safety system, featuring a headlamp and taillight powered by the battery allows you to be seen at any time of day. |
| Telescoping Seat Post | An adjustable and removable seat post allows riders to reach a range of heights while maintaining comfort and stability. |
| Thru Axle | The front wheel features a Thru Axle wheel attachment system for tool-free installation. This feature ensures a straight wheel, consistent brake rotor alignment, and handling stability. Remove the wheel in minutes for an easy and light-weight transport. |
| Grips | Soft durometer ergonomic grips are full-length on both sides and easily customizable. |
| Kickstand | A heavy-duty side-sweeping kickstand located near the chain stay keeps the eBike upright. |
| Hidden Cable Routing | The down tube of the frame houses the main cables for a premium experience at no extra cost. |
| Green Packaging | Packaging components are biodegradable and easily recyclable. |
| Thumb Throttle | An ergonomic below-the-bar trigger throttle designed for your thumb is easily engaged while simultaneously eliminating joint fatigue. |
| Motor | A 750W rear hub-motor (1310W Peak) with 85Nm of torque delivers power and speed quicker than ever before. New Stealth M24 technology is 400% quieter**, delivering a hushed motor experience without sacrificing power. |
| Fat Tires | Puncture-resistant 26” x 4” knobby tires can handle any terrain with ease. Slime is installed to prevent flat tires at no additional cost. |
| Brakes | Hydraulic mineral oil brakes and 180mm rotors (1.8mm thick) offer ultimate stopping power and peace of mind in wet or dry conditions. |
| PAS Sensor | Lectric's new PWR™ allows the rider to control the eBike's output with no additional effort so that a torque sensor is not necessary for smooth rides. Instead, the XPeak has a simply designed and affordable cadence sensor. |
| Crankset | Forged aluminum, 46-tooth ProWheel chainring is the perfect ratio for effortless 26-inch wheel pedaling. |
| LCD Display | A backlit, heads-up LCD display provides trip and battery intelligence on the go. IP-65 rated electrical components ensure greater water and dust resistance. |
| Charging | A charging port on the top of the integrated battery provides riders with the option to charge the eBike without removing the battery. Meanwhile, interchangeable spare batteries can be removed and installed in seconds, doubling your range. |
| eMTB Safety Tested | A US-based bicycle testing lab put the XPeak through the rigorous eMTB safety standard testing process to prove the frame, fork, stem, and handlebars can handle off-road conditions ride after ride. The XPeak is rated to ISO 4210-10 eMTB. |
| Removable Pedals | Quick-release pedals easily detach from the bike for compact transport. |
| Saddle | A custom-designed saddle compliments a sportier look while adding comfort so you can ride longer. |
| Accessory Mounting Points | The XPeak frame features multiple mounting points throughout the eBike for various accessory combinations. |
| Frame | The XPeak is available in 2 different frame styles; a diamond High-Step and an easily mountable Step-Thru. |
| One Minute, Tool-Free Assembly | Simply attach the quick-release pedals and install the front wheel via the thru axle. |
| Safety Certified | The Lectric XPeak is certified to UL 2849. Additionally, the XPeak's lithium-ion battery is certified to UL 2271. |
Size Guide
| Bike Dimensions | 74"L x 25"W x 42"H |
| Stand Over Height | 19.5" |
| Bike Weight | 67 lbs. |
| Payload Capacity | Max: 330 lbs. Never exceed the payload capacity. Distribute weight within the guidelines: Max Rider weight 330 lbs, Max Rear Rack Weight 60 lbs. |
| Seat to Ground | Min: 33” / Max: 45” |
| Rider Height | 5’2” - 6’3” |
| Bike Dimensions with Front Tire removed | 59"L x 25"W x 32"H |
| Handlebar Height | 42" |
| Bike Weight with Front Tire removed | 57.2 lbs. |
| Rider Payload Capacity | Max: 330 lbs. |
| Handlebar Width | 26" |
| Handlebar Reach | 22” - 23” |
Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
