Specifications

Product

Model	051405U
Length × Width × Height	Approx. 1168 × 540 × 1220 mm (45.9 × 21.2 × 48 in)
Folded: Length × Width × Height Approx.	1168 × 538 × 565 mm (45.9 × 21.1 × 22.2 in)
Net Weight/td>	Approx. 41.4 lbs (18.8 kg)

Rider

Max. Payload	265 lbs (120 kg)
Recommended Age	16+
Required Height	4'5''–6'5'' (140–200 cm)

Machine

Max. Speed	Approx. 15.5 mph (25 km/h)
Range at 9.3 mph (15 km/h)	Approx. 24.9 miles (40 km)
Range at 12.4 mph (20 km/h)	Approx. 21.7 miles (35 km)
Range at 15.5 mph (25 km/h)[1]	Approx. 16.8 miles (27 km)
Max. Slope[2]	Approx. 18%
Traversable Terrian	Mostly smooth roads or normal asphalt, tarmac roads
Operating Temperature	14-104F (-10-40C)
Storage Temperature	-4-122F (-20-50C)
IP Rating	IPX4
Duration of Charging	Approx. 5.5 h

Battery

Nominal Voltage	36 V Max.
Charging Voltage	42 V
Charging Temperature	32-113ºF (0-40C)
Nominal Energy	275 Wh
Nominal Capacity	7650 mAh
Battery Management System	Protection against overvoltage/undervoltage/short circuit/overcurrent/over temperature

Motor

Nominal Power	0.35 kW, 350 W
Max. power	0.75 kW, 750 W

Charger

Model	NBW41D001D7D
Output Power	70 W
Input Voltage	100-240 V~ 50-60 Hz
Max. Output Voltage	42 V
Rated Output	41 V 1.7 A

Tires

Tires	10-inch air-leakage-proof tubeless pneumatic tires
Recommended Tire Pressure	45±3 psi
